93AA46/P
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Through Hole 93AA46 Tube ic memory 2MHz 10ms 6.35mm 3mA
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.6688
≥1 USD $0.6688
≥10 USD $0.643456
≥100 USD $0.616352
Inventory: 579
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Plating Tin
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Surface Mount NO
Number of Pins 8
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
Published 2004
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Additional Feature 100K ERASE/WRITE CYCLES MIN; DATA RETENTION > 40 YEARS
Technology CMOS
Voltage - Supply 1.8V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT APPLICABLE
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT APPLICABLE
Base Part Number 93AA46
Pin Count 8
Qualification Status Not Qualified
Operating Supply Voltage 1.8V
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2/5V
Interface Serial
Memory Size 1Kb 128 x 8 64 x 16
Nominal Supply Current 3mA
Memory Type Non-Volatile
Operating Mode SYNCHRONOUS
Clock Frequency 2MHz
Memory Format EEPROM
Memory Interface SPI
Organization 64X16
Output Characteristics 3-STATE
Write Cycle Time - Word, Page 10ms
Density 1 kb
Standby Current-Max 0.00003A
Screening Level TS 16949
Serial Bus Type MICROWIRE
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 10 ms
Data Retention Time-Min 200
Write Protection SOFTWARE
Dimensions
Height 3.3mm
Length 9.27mm
Width 6.35mm
Compliance
RoHS Status ROHS3 Compliant
