34AA04T-E/ST

Microchip Technology
RoHS
RoHS RoHS compliant
Package 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Memory
Description R-PDSO-G8 Surface Mount 34AA04 Tape & Reel (TR) ic memory 1MHz 350ns 3mm 4096bit
PDF
/
Buying Options
Total Price: USD $0.31
Unit Price: USD $0.305906
≥1 USD $0.305906
≥10 USD $0.246825
≥30 USD $0.22188
≥100 USD $0.190371
≥500 USD $0.175929
≥1000 USD $0.168051
Inventory: 6058
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 5 Weeks

Physical

Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP (0.173, 4.40mm Width)

Technical

Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Published 2016
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Technology CMOS
Voltage - Supply 1.7V~3.6V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.2V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 34AA04
JESD-30 Code R-PDSO-G8
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 1.7V
Interface 2-Wire, I2C, Serial
Memory Size 4Kb 256 x 8 x 2
Memory Type Non-Volatile
Operating Mode SYNCHRONOUS
Clock Frequency 1MHz
Access Time 350ns
Memory Format EEPROM
Memory Interface I2C
Organization 512X8
Memory Width 8
Write Cycle Time - Word, Page 5ms
Memory Density 4096 bit
Screening Level TS 16949
Serial Bus Type I2C
Write Cycle Time-Max (tWC) 5ms

Dimensions

Height Seated (Max) 1.2mm
Length 4.4mm
Width 3mm

Compliance

RoHS Status ROHS3 Compliant
