25LC256-I/SM
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount 25LC256 Tube ic memory 10MHz 50ns 5.24mm 6mA
PDF
/
Buying Options
Total Price: USD $1.38
Unit Price: USD $1.3816
≥1 USD $1.3816
≥10 USD $1.341472
≥100 USD $1.31428
Inventory: 9516
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 5.24mm
Length 5.26mm
Height 1.98mm
Technical
Write Protection HARDWARE/SOFTWARE
Data Retention Time-Min 200
Write Cycle Time-Max (tWC) 5ms
Endurance 1000000 Write/Erase Cycles
Serial Bus Type SPI
Standby Current-Max 0.000001A
Density 256 kb
Write Cycle Time - Word, Page 5ms
Memory Interface SPI
Memory Format EEPROM
Access Time 50 ns
Clock Frequency 10MHz
Memory Type Non-Volatile
Nominal Supply Current 6mA
Memory Size 256Kb 32K x 8
Interface SPI, Serial
Operating Supply Voltage 5V
Pin Count 8
Base Part Number 25LC256
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 2.5V~5.5V
Technology CMOS
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2005
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Package / Case 8-SOIC (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 5 Weeks
