25LC080A-E/ST
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount 25LC080A Tube ic memory 10MHz 100ns 3mm 6mA
PDF
/
Buying Options
Total Price: USD $0.76
Unit Price: USD $0.761482
≥1 USD $0.761482
≥200 USD $0.295403
≥500 USD $0.284899
≥1000 USD $0.279648
Inventory: 2753
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2007
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Technology CMOS
Voltage - Supply 2.5V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 25LC080A
Pin Count 8
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 3/5V
Supply Voltage-Min (Vsup) 2.5V
Interface SPI, Serial
Memory Size 8Kb 1K x 8
Nominal Supply Current 6mA
Memory Type Non-Volatile
Clock Frequency 10MHz
Access Time 100 ns
Memory Format EEPROM
Memory Interface SPI
Memory Width 8
Write Cycle Time - Word, Page 5ms
Density 8 kb
Standby Current-Max 0.000005A
Serial Bus Type SPI
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 5 ms
Data Retention Time-Min 200
Write Protection HARDWARE/SOFTWARE
Dimensions
Height Seated (Max) 1.2mm
Length 4.4mm
Width 3mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
