25AA512-I/SM

Microchip Technology
RoHS
RoHS RoHS compliant
Package 8-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Memory
Description EAR99 Surface Mount 25AA512 Tube ic memory 20MHz 250ns 5.38mm 7mA
PDF
/
Buying Options
Total Price: USD $2.09
Unit Price: USD $2.0856
≥1 USD $2.0856
≥10 USD $2.003232
≥100 USD $1.99408
Inventory: 251
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 5 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.209, 5.30mm Width)
Number of Pins 8

Technical

Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2008
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Technology CMOS
Voltage - Supply 1.8V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 25AA512
Pin Count 8
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2.5/5V
Interface SPI, Serial
Memory Size 512Kb 64K x 8
Nominal Supply Current 7mA
Memory Type Non-Volatile
Clock Frequency 20MHz
Access Time 250 ns
Memory Format EEPROM
Memory Interface SPI
Write Cycle Time - Word, Page 5ms
Density 512 kb
Standby Current-Max 0.000001A
Serial Bus Type SPI
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 5ms
Data Retention Time-Min 200
Write Protection HARDWARE/SOFTWARE

Dimensions

Height 1.98mm
Length 5.33mm
Width 5.38mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
