25AA080A-I/ST
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount 25AA080A Tube ic memory 10MHz 160ns 4.4mm 6mA
PDF
/
Buying Options
Total Price: USD $1.48
Unit Price: USD $1.47725
≥1 USD $1.47725
≥10 USD $1.2122
≥100 USD $1.1742
≥500 USD $1.1362
≥1000 USD $1.0982
Inventory: 306
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.4mm
Length 3mm
Height 1mm
Technical
Write Protection HARDWARE/SOFTWARE
Data Retention Time-Min 200
Write Cycle Time-Max (tWC) 5ms
Endurance 1000000 Write/Erase Cycles
Serial Bus Type SPI
Standby Current-Max 0.000001A
Density 8 kb
Write Cycle Time - Word, Page 5ms
Memory Interface SPI
Memory Format EEPROM
Access Time 160 ns
Clock Frequency 10MHz
Memory Type Non-Volatile
Nominal Supply Current 6mA
Memory Size 8Kb 1K x 8
Interface SPI, Serial
Power Supplies 2/5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 8
Base Part Number 25AA080A
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 2.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 1.8V~5.5V
Technology CMOS
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2007
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 6 Weeks
