25AA040XT/ST
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount 25AA040 Tape & Reel (TR) ic memory 1MHz 5ms 3mm 0.000002A
PDF
/
Buying Options
Total Price: USD $1.35
Unit Price: USD $1.354913
≥1 USD $1.354913
≥200 USD $0.540915
≥500 USD $0.522534
≥1000 USD $0.513344
Inventory: 9376
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Number of Pins 8
Technical
Operating Temperature 0°C~70°C TA
Packaging Tape & Reel (TR)
Published 2003
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature DATA RETENTION > 200 YEARS; 1M ENDURANCE CYCLES
Technology CMOS
Voltage - Supply 1.8V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 1.8V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 25AA040
Pin Count 8
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2/5V
Interface SPI, Serial
Memory Size 4Kb 512 x 8
Memory Type Non-Volatile
Clock Frequency 1MHz
Supply Current-Max 0.005mA
Access Time 5 ms
Memory Format EEPROM
Memory Interface SPI
Memory Width 8
Density 4 kb
Standby Current-Max 0.000002A
Serial Bus Type SPI
Endurance 1000000 Write/Erase Cycles
Data Retention Time-Min 200
Write Protection HARDWARE/SOFTWARE
Dimensions
Height Seated (Max) 1.2mm
Length 4.4mm
Width 3mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
