25AA040XT-I/ST

Microchip Technology
RoHS
RoHS RoHS compliant
Package 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Memory
Description EAR99 Surface Mount 25AA040 Tape & Reel (TR) ic memory 1MHz 475ns 3mm 5mA
PDF
/
Buying Options
Total Price: USD $0.44
Unit Price: USD $0.439822
≥1 USD $0.439822
≥10 USD $0.36236
≥30 USD $0.324286
≥100 USD $0.286212
≥500 USD $0.263893
≥1000 USD $0.252077
Inventory: 7664
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 3mm
Length 4.4mm
Height Seated (Max) 1.2mm

Technical

Write Protection HARDWARE/SOFTWARE
Data Retention Time-Min 200
Write Cycle Time-Max (tWC) 5ms
Endurance 1000000 Write/Erase Cycles
Serial Bus Type SPI
Standby Current-Max 0.000001A
Density 4 kb
Write Cycle Time - Word, Page 5ms
Memory Width 8
Memory Interface SPI
Memory Format EEPROM
Access Time 475 ns
Clock Frequency 1MHz
Memory Type Non-Volatile
Nominal Supply Current 5mA
Memory Size 4Kb 512 x 8
Interface SPI, Serial
Power Supplies 2/5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 8
Base Part Number 25AA040
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 2.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 1.8V~5.5V
Technology CMOS
Additional Feature DATA RETENTION > 200 YEARS; 1M ENDURANCE CYCLES
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA

Physical

Number of Pins 8
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin

Supply Chain

Factory Lead Time 6 Weeks
