24VL025/ST
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount 24VL025 Tube ic memory 400kHz 900ns 3mm 3mA
PDF
/
Inventory: 1929
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Number of Pins 8
Technical
Operating Temperature -20°C~85°C TA
Packaging Tube
Published 2009
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Technology CMOS
Voltage - Supply 1.5V~3.6V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 1.8V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 24VL025
Pin Count 8
Qualification Status Not Qualified
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 1.5V
Interface 2-Wire, Serial
Memory Size 2Kb 256 x 8
Nominal Supply Current 3mA
Memory Type Non-Volatile
Operating Mode SYNCHRONOUS
Clock Frequency 400kHz
Access Time 900ns
Memory Format EEPROM
Memory Interface I2C
Memory Width 8
Write Cycle Time - Word, Page 5ms
Density 2 kb
Standby Current-Max 0.000001A
Serial Bus Type I2C
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 5ms
Data Retention Time-Min 200
Write Protection SOFTWARE
I2C Control Byte 1010DDDR
Dimensions
Height Seated (Max) 1.2mm
Length 4.4mm
Width 3mm
Compliance
RoHS Status ROHS3 Compliant
