24VL014H/MS
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount 24VL014H Tube ic memory 400kHz 900ns 3mm 3mA
PDF
/
Inventory: 1153
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Nominal Supply Current 3mA
Memory Type Non-Volatile
Operating Mode SYNCHRONOUS
Clock Frequency 400kHz
Memory Size 1Kb 128 x 8
Interface I2C, Serial
Supply Voltage-Min (Vsup) 1.5V
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Qualification Status Not Qualified
Pin Count 8
Base Part Number 24VL014H
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 1.8V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 1.5V~3.6V
Technology CMOS
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2008
Packaging Tube
Operating Temperature -20°C~85°C TA
I2C Control Byte 1010DDDR
Write Protection HARDWARE
Data Retention Time-Min 200
Write Cycle Time-Max (tWC) 5 ms
Endurance 1000000 Write/Erase Cycles
Serial Bus Type I2C
Standby Current-Max 0.000001A
Density 1 kb
Write Cycle Time - Word, Page 5ms
Memory Width 8
Memory Interface I2C
Memory Format EEPROM
Access Time 900ns
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 5 Weeks
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 1.1mm
