24LC65T/SM
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount 24LC65 Tape & Reel (TR) ic memory 400kHz 900ns 5.21mm 3mA
PDF
/
Buying Options
Total Price: USD $0.53
Unit Price: USD $0.532
≥1 USD $0.532
≥10 USD $0.437
≥100 USD $0.42275
≥500 USD $0.40945
≥1000 USD $0.39615
Inventory: 3754
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.209, 5.30mm Width)
Number of Pins 8
Technical
Operating Temperature 0°C~70°C TA
Packaging Tape & Reel (TR)
Published 2005
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Additional Feature DATA RETENTION > 200 YEARS; 1000000 ERASE/WRITE CYCLES GUARANTEED
Technology CMOS
Voltage - Supply 2.5V~6.0V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 24LC65
Pin Count 8
I2C Control Byte 1010DDDR
Write Protection SOFTWARE
Data Retention Time-Min 200
Write Cycle Time-Max (tWC) 5ms
Endurance 100000 Write/Erase Cycles
Serial Bus Type I2C
Standby Current-Max 0.00005A
Density 64 kb
Write Cycle Time - Word, Page 5ms
Memory Width 8
Output Characteristics OPEN-DRAIN
Memory Interface I2C
Memory Format EEPROM
Access Time 900ns
Clock Frequency 400kHz
Memory Type Non-Volatile
Nominal Supply Current 3mA
Memory Size 64Kb 8K x 8
Interface I2C, Serial
Supply Voltage-Min (Vsup) 2.5V
Power Supplies 3/5V
Supply Voltage-Max (Vsup) 6V
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 5.21mm
Height Seated (Max) 2.03mm
