24LC04BHT-I/ST
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount 24LC04BH Tape & Reel (TR) ic memory 400kHz 900ns 3mm 3mA
PDF
/
Inventory: 8326
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2007
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Technology CMOS
Voltage - Supply 2.5V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 24LC04BH
Pin Count 8
Operating Supply Voltage 5V
Interface I2C, Serial
Memory Size 4Kb 256 x 8 x 2
Nominal Supply Current 3mA
Memory Type Non-Volatile
Clock Frequency 400kHz
Access Time 900ns
Memory Format EEPROM
Memory Interface I2C
Output Characteristics OPEN-DRAIN
Memory Width 8
Write Cycle Time - Word, Page 5ms
Density 4 kb
Standby Current-Max 0.000005A
Screening Level ISO/TS-16949
Serial Bus Type I2C
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 5ms
Data Retention Time-Min 200
Write Protection HARDWARE
Data Polling YES
Page Size 16words
I2C Control Byte 1010XXMR
Reverse Pinout NO
Dimensions
Height Seated (Max) 1.2mm
Length 4.4mm
Width 3mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
