24LC04BHT-I/OT
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount 24LC04BH Tape & Reel (TR) ic memory 400kHz 900ns 1.6mm 3mA
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.264
≥1 USD $0.264
≥10 USD $0.24464
≥100 USD $0.237952
Inventory: 1275
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Number of Pins 5
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2002
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Technology CMOS
Voltage - Supply 2.5V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 24LC04BH
Pin Count 5
Operating Supply Voltage 5V
Interface I2C, Serial
Memory Size 4Kb 256 x 8 x 2
Nominal Supply Current 3mA
Memory Type Non-Volatile
Clock Frequency 400kHz
Access Time 900ns
Memory Format EEPROM
Memory Interface I2C
Output Characteristics OPEN-DRAIN
Memory Width 8
Write Cycle Time - Word, Page 5ms
Density 4 kb
Screening Level ISO/TS-16949
Serial Bus Type I2C
Endurance 1000000 Write/Erase Cycles
Data Retention Time-Min 200
Write Protection HARDWARE
Data Polling YES
Page Size 16words
I2C Control Byte 1010XXMR
Reverse Pinout NO
Dimensions
Length 2.9mm
Width 1.6mm
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
