24LC024H-E/SN
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount 24LC024H Tube ic memory 1MHz 400ns 3.9mm 3mA
PDF
/
Buying Options
Total Price: USD $0.41
Unit Price: USD $0.412886
≥1 USD $0.412886
≥10 USD $0.38952
≥100 USD $0.367469
≥500 USD $0.346671
≥1000 USD $0.327043
Inventory: 9202
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Write Cycle Time-Max (tWC) 5ms
Serial Bus Type I2C
Density 2 kb
Write Cycle Time - Word, Page 5ms
Memory Width 8
Memory Interface I2C
Memory Format EEPROM
Access Time 400ns
Clock Frequency 1MHz
Memory Type Non-Volatile
Nominal Supply Current 3mA
Memory Size 2Kb 256 x 8
Interface I2C, Serial
Operating Supply Voltage 5V
Pin Count 8
Base Part Number 24LC024H
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Supply Voltage 4.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 2.5V~5.5V
Technology CMOS
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2008
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 3 Weeks
