24LC01B-I/SNG
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount 24LC01B Tube ic memory 400kHz 3500ns 3.9mm 0.000005A
PDF
/
Buying Options
Total Price: USD $7.01
Unit Price: USD $7.011
≥1 USD $7.011
≥10 USD $5.7532
≥100 USD $5.5727
≥500 USD $5.39315
≥1000 USD $5.2136
Inventory: 2501
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2005
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
HTS Code 8542.32.00.51
Technology CMOS
Voltage - Supply 2.5V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 24LC01B
Pin Count 8
JESD-30 Code R-PDSO-G8
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 3/5V
Supply Voltage-Min (Vsup) 2.5V
Memory Size 1Kb 128 x 8
Memory Type Non-Volatile
Operating Mode SYNCHRONOUS
Clock Frequency 400kHz
Supply Current-Max 0.003mA
Access Time 3500ns
Memory Format EEPROM
Memory Interface I2C
Organization 128X8
Memory Width 8
Write Cycle Time - Word, Page 5ms
Standby Current-Max 0.000005A
Memory Density 1024 bit
Parallel/Serial SERIAL
Serial Bus Type I2C
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 5 ms
Data Retention Time-Min 200
Write Protection HARDWARE
I2C Control Byte 1010XXXR
Reverse Pinout NO
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
