24LC014-E/MS
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Memory
Description
Surface Mount 24LC014 Tube CMOS ic memory 400kHz 900ns 3mm 3mA
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.399556
≥1 USD $0.399556
≥10 USD $0.376946
≥100 USD $0.355614
≥500 USD $0.335473
≥1000 USD $0.316493
Inventory: 2058
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Plating Tin
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Surface Mount YES
Number of Pins 8
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2010
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Technology CMOS
Voltage - Supply 2.5V~5.5V
Terminal Position DUAL
Number of Functions 1
Terminal Pitch 0.65mm
Base Part Number 24LC014
Operating Supply Voltage 5V
Interface I2C, Serial
Memory Size 1Kb 128 x 8
Nominal Supply Current 3mA
Memory Type Non-Volatile
Clock Frequency 400kHz
Access Time 900ns
Memory Format EEPROM
Memory Interface I2C
Memory Width 8
Write Cycle Time - Word, Page 5ms
Density 1 kb
Standby Current-Max 0.000001A
Serial Bus Type I2C
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 5ms
Data Retention Time-Min 200
Write Protection HARDWARE
I2C Control Byte 1010DDDR
Dimensions
Height Seated (Max) 1.1mm
Length 3mm
Width 3mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
