24FC64F-I/SN
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
e3 Surface Mount 24FC64F Tube ic memory 1MHz 400ns 3.9mm 0.000001A
PDF
/
Buying Options
Total Price: USD $0.46
Unit Price: USD $0.4576
≥1 USD $0.4576
≥10 USD $0.444224
≥100 USD $0.426008
Inventory: 874
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
I2C Control Byte 1010DDDR
Write Protection HARDWARE
Data Retention Time-Min 200
Write Cycle Time-Max (tWC) 5ms
Endurance 1000000 Write/Erase Cycles
Serial Bus Type I2C
Standby Current-Max 0.000001A
Density 64 kb
Write Cycle Time - Word, Page 5ms
Memory Width 8
Memory Interface I2C
Memory Format EEPROM
Access Time 400ns
Supply Current-Max 0.003mA
Clock Frequency 1MHz
Operating Mode SYNCHRONOUS
Memory Type Non-Volatile
Memory Size 64Kb 8K x 8
Interface I2C, Serial
Supply Voltage-Min (Vsup) 1.7V
Power Supplies 2/5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status Not Qualified
Base Part Number 24FC64F
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 1.7V~5.5V
Technology CMOS
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2012
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 6 Weeks
