24FC512T-I/SM
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount 24FC512 Tape & Reel (TR) ic memory 1MHz 400ns 5.23mm 5mA
PDF
/
Buying Options
Total Price: USD $1.58
Unit Price: USD $1.5752
≥1 USD $1.5752
≥10 USD $1.5048
≥100 USD $1.472944
Inventory: 1331
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 5.23mm
Length 5.245mm
Height Seated (Max) 2.03mm
Technical
I2C Control Byte 1010DDDR
Write Protection HARDWARE
Data Retention Time-Min 200
Write Cycle Time-Max (tWC) 5ms
Endurance 1000000 Write/Erase Cycles
Serial Bus Type I2C
Standby Current-Max 0.000001A
Density 512 kb
Write Cycle Time - Word, Page 5ms
Memory Width 8
Memory Interface I2C
Memory Format EEPROM
Access Time 400ns
Clock Frequency 1MHz
Memory Type Non-Volatile
Nominal Supply Current 5mA
Memory Size 512Kb 64K x 8
Interface 2-Wire, I2C, Serial
Supply Voltage-Min (Vsup) 1.7V
Power Supplies 2/5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 8
Base Part Number 24FC512
Terminal Pitch 1.27mm
Supply Voltage 2.5V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 1.7V~5.5V
Technology CMOS
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Package / Case 8-SOIC (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 5 Weeks
