24FC01T-E/MS
RoHS
/
Package 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Memory
Description
S-PDSO-G8 Surface Mount Tape & Reel (TR) 128X8 ic memory 1MHz 450ns 3mm 0.000003A
PDF
/
Buying Options
Total Price: USD $0.3
Unit Price: USD $0.2992
≥1 USD $0.2992
≥10 USD $0.272096
≥100 USD $0.262856
Inventory: 1176
Minimum: 1
-
+
Technical Details
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 1.1mm
Technical
Reverse Pinout NO
I2C Control Byte 1010XXXR
Write Protection HARDWARE
Data Retention Time-Min 200
Write Cycle Time-Max (tWC) 5ms
Endurance 1000000 Write/Erase Cycles
Serial Bus Type I2C
Parallel/Serial SERIAL
Memory Density 1024 bit
Standby Current-Max 0.000003A
Write Cycle Time - Word, Page 5ms
Memory Width 8
Organization 128X8
Memory Interface I2C
Memory Format EEPROM
Access Time 450ns
Supply Current-Max 0.003mA
Clock Frequency 1MHz
Operating Mode SYNCHRONOUS
Memory Type Non-Volatile
Memory Size 1Kb 128 x 8
Supply Voltage-Min (Vsup) 1.7V
Supply Voltage-Max (Vsup) 5.5V
JESD-30 Code S-PDSO-G8
Terminal Pitch 0.65mm
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 1.7V~5.5V
Technology CMOS
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Surface Mount YES
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
