24C65/P
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Through Hole 24C65 Tube ic memory 400kHz 900ns 7.112mm 3mA
PDF
/
Buying Options
Total Price: USD $2.22
Unit Price: USD $2.2176
≥1 USD $2.2176
≥10 USD $2.129952
≥100 USD $2.057528
Inventory: 97
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 7.112mm
Length 10.16mm
Height 4.953mm
Technical
I2C Control Byte 1010DDDR
Write Protection SOFTWARE
Data Retention Time-Min 200
Write Cycle Time-Max (tWC) 5 ms
Endurance 100000 Write/Erase Cycles
Serial Bus Type I2C
Standby Current-Max 0.000005A
Density 64 kb
Write Cycle Time - Word, Page 5ms
Output Characteristics OPEN-DRAIN
Memory Interface I2C
Memory Format EEPROM
Access Time 900ns
Clock Frequency 400kHz
Memory Type Non-Volatile
Nominal Supply Current 3mA
Memory Size 64Kb 8K x 8
Interface 2-Wire, I2C, Serial
Power Supplies 5V
Supply Voltage-Max (Vsup) 6V
Operating Supply Voltage 5V
Pin Count 8
Base Part Number 24C65
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 4.5V~6V
Technology CMOS
Additional Feature DATA RETENTION > 200 YEARS; 1000000 ERASE/WRITE CYCLES GUARANTEED
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2003
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 7 Weeks
