24C01C-E/P
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Memory
Description
e3 Through Hole 24C01C Tube ic memory 100kHz 3500ns 7.62mm 3mA
PDF
/
Buying Options
Total Price: USD $0.5
Unit Price: USD $0.497379
≥1 USD $0.497379
≥10 USD $0.46923
≥100 USD $0.442671
≥500 USD $0.417607
≥1000 USD $0.393979
Inventory: 1248
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7.62mm
Length 9.27mm
Height Seated (Max) 5.334mm
Technical
I2C Control Byte 1010DDDR
Data Retention Time-Min 200
Write Cycle Time-Max (tWC) 1.5ms
Endurance 1000000 Write/Erase Cycles
Serial Bus Type I2C
Standby Current-Max 0.00005A
Density 1 kb
Write Cycle Time - Word, Page 1.5ms
Memory Width 8
Memory Interface I2C
Memory Format EEPROM
Access Time 3500ns
Clock Frequency 100kHz
Memory Type Non-Volatile
Nominal Supply Current 3mA
Memory Size 1Kb 128 x 8
Interface I2C, Serial
Power Supplies 5V
Operating Supply Voltage 5V
Pin Count 8
Base Part Number 24C01C
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Additional Feature DATA RETENTION > 200 YEARS, 1000000 ERASE/WRITE CYCLES GUARANTEED
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2008
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 7 Weeks
