24AA32AT-I/MC
RoHS
RoHS compliant
RoHS compliantPackage 8-VFDFN Exposed Pad
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount 24AA32A Cut Tape (CT) ic memory 400kHz 900ns 2mm 3mA
PDF
/
Buying Options
Total Price: USD $0.51
Unit Price: USD $0.5104
≥1 USD $0.5104
≥10 USD $0.498432
≥100 USD $0.480392
Inventory: 14394
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-VFDFN Exposed Pad
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Cut Tape (CT)
Published 2005
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature 2-WIRE SERIAL INTERFACE; DATA RETENTION > 200 YEARS; 1000000 ERASE/WRITE CYCLES GUARANTEED
Technology CMOS
Voltage - Supply 1.8V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.5V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 24AA32A
Pin Count 8
Operating Supply Voltage 5V
Supply Voltage-Min (Vsup) 1.7V
Interface 2-Wire, I2C, Serial
Memory Size 32Kb 4K x 8
Nominal Supply Current 3mA
Memory Type Non-Volatile
Clock Frequency 400kHz
Access Time 900ns
Memory Format EEPROM
Memory Interface I2C
Write Cycle Time - Word, Page 5ms
Density 32 kb
Standby Current-Max 0.000001A
Serial Bus Type I2C
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 5 ms
Data Retention Time-Min 200
Write Protection HARDWARE
I2C Control Byte 1010DDDR
Dimensions
Height 950μm
Length 3mm
Width 2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
