24AA1025-I/SN
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount 24AA1025 Tube ic memory 400kHz 900ns 3.9mm 5mA
PDF
/
Buying Options
Total Price: USD $3.45
Unit Price: USD $3.4496
≥1 USD $3.4496
≥10 USD $3.344704
≥100 USD $3.251688
Inventory: 185
Minimum: 1
-
+
Technical Details
Technical
Number of Functions 1
Supply Voltage 2.5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 24AA1025
Pin Count 8
Operating Supply Voltage 5V
Supply Voltage-Min (Vsup) 1.7V
Interface I2C, Serial
Memory Size 1Mb 128K x 8
Nominal Supply Current 5mA
Memory Type Non-Volatile
Clock Frequency 400kHz
Access Time 900ns
Memory Format EEPROM
Memory Interface I2C
Write Cycle Time - Word, Page 5ms
Density 1 Mb
Standby Current-Max 0.000005A
Serial Bus Type I2C
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 1.7V~5.5V
Technology CMOS
Additional Feature 200 YEARS DATA RETENTION
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2011
Packaging Tube
Operating Temperature -40°C~85°C TA
I2C Control Byte 1010MDDR
Write Protection HARDWARE
Data Retention Time-Min 200
Write Cycle Time-Max (tWC) 5 ms
Endurance 1000000 Write/Erase Cycles
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 7 Weeks
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Height 1.5mm
