24AA044-I/MS
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Memory
Description
e3 Surface Mount 24AA044 Tube ic memory 1MHz 400ns 3mm 4Kb 256x 8x 2
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.3344
≥1 USD $0.3344
≥10 USD $0.326304
≥100 USD $0.31724
Inventory: 891
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2014
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Technology CMOS
Voltage - Supply 1.7V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 24AA044
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 1.7V
Interface 2-Wire, I2C, Serial
Memory Size 4Kb 256 x 8 x 2
Memory Type Non-Volatile
Operating Mode SYNCHRONOUS
Clock Frequency 1MHz
Access Time 400ns
Memory Format EEPROM
Memory Interface I2C
Memory Width 8
Write Cycle Time - Word, Page 5ms
Screening Level TS 16949
Serial Bus Type I2C
Write Cycle Time-Max (tWC) 5ms
Dimensions
Height Seated (Max) 1.1mm
Length 3mm
Width 3mm
Compliance
RoHS Status ROHS3 Compliant
