11AA040-I/P image
Favorite
11AA040-I/P image
Favorite
RoHS
RoHS RoHS compliant
Package 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Memory
Description SOFTWARE Active Tin 1-WIRE EEPROM Memory -40C~85C TA 2/5V 4kb 5mA
PDF
/
Inventory: 1359
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Width 6.35mm
Length 9.46mm
Height 3.3mm

Technical

Write Protection SOFTWARE
Data Retention Time-Min 200
Write Cycle Time-Max (tWC) 10ms
Endurance 1000000 Write/Erase Cycles
Serial Bus Type 1-WIRE
Standby Current-Max 0.000005A
Density 4 kb
Memory Interface Single Wire
Memory Format EEPROM
Access Time 5 ms
Clock Frequency 100kHz
Memory Type Non-Volatile
Nominal Supply Current 5mA
Memory Size 4Kb 512 x 8
Interface Serial
Power Supplies 2/5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 8
Base Part Number 11AA040
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 1.8V~5.5V
Technology CMOS
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2008
Packaging Tube
Operating Temperature -40°C~85°C TA

Physical

Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin

Supply Chain

Factory Lead Time 10 Weeks
