11AA02UIDT-I/SN
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
e3 Surface Mount 11AA02UID Tape & Reel (TR) ic memory 100kHz 5ms 3.9mm 5mA
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.38191
≥1 USD $0.38191
≥200 USD $0.147793
≥500 USD $0.142607
≥1000 USD $0.140034
Inventory: 3091
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Write Cycle Time-Max (tWC) 5ms
Serial Bus Type SPI
Screening Level TS 16949
Density 2 kb
Write Cycle Time - Word, Page 5ms
Memory Width 8
Memory Interface Single Wire
Memory Format EEPROM
Clock Frequency 100kHz
Operating Mode SYNCHRONOUS
Memory Type Non-Volatile
Nominal Supply Current 5mA
Memory Size 2Kb 256 x 8
Interface Serial
Supply Voltage-Max (Vsup) 5.5V
Base Part Number 11AA02UID
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 1.8V~5.5V
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2013
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
