MX29SL802CTXHI-90G
RoHS
/
Package TFBGA
Category Integrated Circuits (ICs) / Memory
Description
BALL TOP Parallel BOTTOM ic memory 85C 1.65V 8Mb 0.000005A
PDF
/
Buying Options
Total Price: USD $3.76
Unit Price: USD $3.75915
≥1 USD $3.75915
≥10 USD $3.08465
≥100 USD $2.98775
≥500 USD $2.8918
≥1000 USD $2.79585
Inventory: 1190
Minimum: 1
-
+
Technical Details
Physical
Package / Case TFBGA
Surface Mount YES
Technical
Number of Terminations 48
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8542.32.00.51
Subcategory Flash Memories
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 1.8V
Terminal Pitch 0.5mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 48
JESD-30 Code R-PBGA-B48
Qualification Status Not Qualified
Operating Supply Voltage 1.8V
Supply Voltage-Max (Vsup) 2.2V
Power Supplies 1.8/2V
Temperature Grade INDUSTRIAL
Supply Voltage-Min (Vsup) 1.65V
Interface Parallel
Memory Type FLASH, NOR
Operating Mode ASYNCHRONOUS
Supply Current-Max 0.025mA
Access Time 90 ns
Organization 512KX16
Memory Width 16
Density 8 Mb
Standby Current-Max 0.000005A
Alternate Memory Width 8
Data Polling YES
Toggle Bit YES
Number of Sectors/Size 12115
Sector Size 16K8K32K64K
Ready/Busy YES
Boot Block TOP
Dimensions
Height Seated (Max) 0.75mm
Length 6mm
Width 5mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
