MX29SL800CBXEI-90G
RoHS
/
Package /
Category Integrated Circuits (ICs) / Memory
Description
BALL BOTTOM Parallel BOTTOM ic memory 85C 1.65V 8Mb 0.000005A
PDF
/
Inventory: 4900
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 6mm
Length 8mm
Height Seated (Max) 1.3mm
Technical
Boot Block BOTTOM
Ready/Busy YES
Sector Size 16K8K32K64K
Number of Sectors/Size 12115
Toggle Bit YES
Data Polling YES
Alternate Memory Width 8
Standby Current-Max 0.000005A
Density 8 Mb
Memory Width 16
Organization 512KX16
Access Time 90 ns
Supply Current-Max 0.025mA
Operating Mode ASYNCHRONOUS
Memory Type FLASH, NOR
Interface Parallel
Supply Voltage-Min (Vsup) 1.65V
Temperature Grade INDUSTRIAL
Power Supplies 1.8/2V
Supply Voltage-Max (Vsup) 2.2V
Operating Supply Voltage 1.8V
Qualification Status Not Qualified
JESD-30 Code R-PBGA-B48
Pin Count 48
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 0.8mm
Supply Voltage 1.8V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Flash Memories
HTS Code 8542.32.00.51
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 48
Physical
Surface Mount YES
