MX29LV400CTXBC-70G
RoHS
RoHS compliant
RoHS compliantPackage 48-TFBGA, CSPBGA
Category Integrated Circuits (ICs) / Memory
Description
Active TOP 2012 BOTTOM FLASH Memory 0C~70C TA 2.7V 67108864bit 0.000005A
PDF
/
Inventory: 1093
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 6mm
Length 8mm
Height Seated (Max) 1.2mm
Technical
Common Flash Interface YES
Boot Block TOP
Ready/Busy YES
Sector Size 16K8K32K64K
Number of Sectors/Size 1217
Command User Interface YES
Toggle Bit YES
Data Polling YES
Alternate Memory Width 8
Programming Voltage 3V
Access Time (Max) 70 ns
Memory Density 67108864 bit
Standby Current-Max 0.000005A
Write Cycle Time - Word, Page 70ns
Memory Width 16
Organization 4MX16
Memory Interface Parallel
Memory Format FLASH
Supply Current-Max 0.03mA
Operating Mode ASYNCHRONOUS
Memory Type Non-Volatile
Memory Size 4Mb 512K x 8
Supply Voltage-Min (Vsup) 2.7V
Power Supplies 3/3.3V
Supply Voltage-Max (Vsup) 3.6V
Qualification Status Not Qualified
JESD-30 Code R-PBGA-B48
Pin Count 48
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.8mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position BOTTOM
Voltage - Supply 2.7V~3.6V
Technology FLASH - NOR
HTS Code 8542.32.00.51
Terminal Finish TIN SILVER COPPER
ECCN Code 3A991.B.1.A
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Series MX29LV
Published 2012
Packaging Tray
Operating Temperature 0°C~70°C TA
Physical
Surface Mount YES
Package / Case 48-TFBGA, CSPBGA
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
