MX29F400CTTI-90G
RoHS
/
Package TFSOP
Category Integrated Circuits (ICs) / Memory
Description
GULL WING TOP Parallel 100000Write/Erase Cycles ic memory 85C 4.5V 4194304bit 0.000005A
PDF
/
Inventory: 9428
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 12mm
Length 18.4mm
Height Seated (Max) 1.2mm
Technical
Boot Block TOP
Ready/Busy YES
Sector Size 16K8K32K64K
Number of Sectors/Size 1217
Toggle Bit YES
Data Polling YES
Alternate Memory Width 8
Write Cycle Time-Max (tWC) 90ms
Endurance 100000 Write/Erase Cycles
Programming Voltage 5V
Access Time (Max) 90 ns
Memory Density 4194304 bit
Standby Current-Max 0.000005A
Memory Width 16
Organization 256KX16
Supply Current-Max 0.05mA
Operating Mode ASYNCHRONOUS
Memory Type FLASH, NOR
Interface Parallel
Supply Voltage-Min (Vsup) 4.5V
Temperature Grade INDUSTRIAL
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G48
Pin Count 48
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.5mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Flash Memories
HTS Code 8542.32.00.51
Additional Feature TOP BOOT BLOCK
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3
Pbfree Code yes
JESD-609 Code e3
Physical
Surface Mount YES
Package / Case TFSOP
