CY7C1565KV18-450BZXI
RoHS
RoHS compliant
RoHS compliantPackage 165-LBGA
Category Integrated Circuits (ICs) / Memory
Description
Synchronous Obsolete 3-STATE 2003 SRAM Memory -40C~85C TA 1.7V 72Mb 1.1A
PDF
/
Buying Options
Total Price: USD $500.55
Unit Price: USD $500.5528
≥1 USD $500.5528
Inventory: 911
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 15mm
Height Seated (Max) 1.4mm
Technical
Standby Voltage-Min 1.7V
Word Size 36b
Sync/Async Synchronous
I/O Type SEPARATE
Standby Current-Max 0.34A
Density 72 Mb
Address Bus Width 19b
Memory Width 36
Output Characteristics 3-STATE
Memory Interface Parallel
Memory Format SRAM
Access Time 450 ps
Clock Frequency 450MHz
Memory Type Volatile
Nominal Supply Current 1.1A
Number of Ports 2
Memory Size 72Mb 2M x 36
Supply Voltage-Min (Vsup) 1.7V
Supply Voltage-Max (Vsup) 1.9V
Operating Supply Voltage 1.8V
Pin Count 165
Base Part Number CY7C1565
Time@Peak Reflow Temperature-Max (s) 20
Terminal Pitch 1mm
Supply Voltage 1.8V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position BOTTOM
Voltage - Supply 1.7V~1.9V
Technology SRAM - Synchronous, QDR II+
Additional Feature PIPELINED ARCHITECTURE
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 165
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e1
Published 2003
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 165
Package / Case 165-LBGA
Mounting Type Surface Mount
Mount Surface Mount
