CY7C025E-55AXC
RoHS
RoHS compliant
RoHS compliantPackage 100-LQFP
Category Integrated Circuits (ICs) / Memory
Description
Asynchronous Obsolete 3-STATE 2004 SRAM Memory 0C~70C TA 5V 128kb 230mA
PDF
/
Buying Options
Total Price: USD $1.45
Unit Price: USD $1.445503
≥1 USD $1.445503
≥200 USD $0.559295
≥500 USD $0.539602
≥1000 USD $0.530412
Inventory: 4530
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 100-LQFP
Number of Pins 100
Technical
Operating Temperature 0°C~70°C TA
Packaging Tray
Published 2004
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology SRAM - Dual Port, Asynchronous
Voltage - Supply 4.5V~5.5V
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number CY7C025
Pin Count 100
Operating Supply Voltage 5V
Power Supplies 5V
Memory Size 128Kb 8K x 16
Number of Ports 2
Nominal Supply Current 230mA
Memory Type Volatile
Memory Format SRAM
Memory Interface Parallel
Organization 8KX16
Output Characteristics 3-STATE
Memory Width 16
Write Cycle Time - Word, Page 55ns
Address Bus Width 26b
Density 128 kb
Standby Current-Max 0.0015A
Access Time (Max) 55 ns
I/O Type COMMON
Sync/Async Asynchronous
Word Size 16b
Standby Voltage-Min 2V
Dimensions
Height Seated (Max) 1.6mm
Length 14mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
