CY14E256Q1A-SXI
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
Obsolete 2008 SPI Serial DUAL NVSRAM Memory -40C~85C TA 4.5V 262144bit 3.8985mm
PDF
/
Buying Options
Total Price: USD $6.17
Unit Price: USD $6.1688
≥1 USD $6.1688
Inventory: 540
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.8985mm
Length 4.889mm
Height Seated (Max) 1.727mm
Technical
Memory Density 262144 bit
Memory Width 8
Organization 32KX8
Memory Interface SPI
Memory Format NVSRAM
Clock Frequency 40MHz
Operating Mode SYNCHRONOUS
Memory Type Non-Volatile
Memory Size 256Kb 32K x 8
Interface SPI, Serial
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
JESD-30 Code R-PDSO-G8
Base Part Number CY14E256
Time@Peak Reflow Temperature-Max (s) 20
Reach Compliance Code unknown
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology NVSRAM (Non-Volatile SRAM)
HTS Code 8542.32.00.41
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code 3A991.B.2.A
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e4
Published 2008
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
