CY14B101P-SFXI
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Memory
Description
Obsolete Tin 2007 SPI Serial NVSRAM Memory 1W -40C~85C TA 2.7V 1Mb
PDF
/
Buying Options
Total Price: USD $9.13
Unit Price: USD $9.1344
≥1 USD $9.1344
Inventory: 791
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 10.2865mm
Height Seated (Max) 2.667mm
Technical
Word Size 8b
Standby Current-Max 0.005A
Density 1 Mb
Memory Width 8
Organization 128KX8
Data Bus Width 8b
Memory Interface SPI
Memory Format NVSRAM
Access Time 15 ns
Clock Frequency 40MHz
Memory Type Non-Volatile
Nominal Supply Current 10mA
Memory Size 1Mb 128K x 8
Interface SPI, Serial
Supply Voltage-Min (Vsup) 2.7V
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3V
Pin Count 16
Base Part Number CY14B101
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 2.7V~3.6V
Technology NVSRAM (Non-Volatile SRAM)
Max Power Dissipation 1W
Subcategory SRAMs
HTS Code 8542.32.00.41
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Published 2007
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 16
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
