DP8421AVX-25
RoHS
/
Package 68-LCC (J-Lead)
Category Integrated Circuits (ICs) / Memory - Controllers
Description
DP8421 Not Qualified Tape & Reel (TR) S-PQCC-J68 memory controller 95mA 24.2316mm 4.5V~5.5V 0C~70C
PDF
/
Buying Options
Total Price: USD $23.3
Unit Price: USD $23.2959
≥1 USD $23.2959
≥10 USD $19.11495
≥100 USD $18.5174
≥500 USD $17.91985
≥1000 USD $17.32325
Inventory: 1000
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 24.2316mm
Length 24.2316mm
Height Seated (Max) 5.08mm
Technical
Memory Organization 1M X 1
Number of Banks 4
Controller Type Dynamic RAM (DRAM)
Low Power Mode YES
Boundary Scan NO
Address Bus Width 20
Supply Current-Max 95mA
Clock Frequency 25MHz
uPs/uCs/Peripheral ICs Type MEMORY CONTROLLER, DRAM
Power Supplies 5V
Qualification Status Not Qualified
JESD-30 Code S-PQCC-J68
Base Part Number DP8421
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 1.27mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form J BEND
Terminal Position QUAD
Voltage - Supply 4.5V~5.5V
Technology CMOS
Subcategory Memory Controllers
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 68
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 68-LCC (J-Lead)
Mounting Type Surface Mount
