DS1212+
RoHS
RoHS compliant
RoHS compliantPackage 28-DIP (0.600, 15.24mm)
Category Integrated Circuits (ICs) / Memory - Controllers
Description
Through Hole Lead Free DUAL Matte Tin (Sn) Nonvolatile RAM IC Controller 0C~70C 4.75V~5.5V 15.24mm 80mA
PDF
/
Buying Options
Total Price: USD $51.95
Unit Price: USD $51.954294
≥1 USD $51.954294
≥10 USD $49.013489
≥100 USD $46.239134
≥500 USD $43.62183
≥1000 USD $41.15267
Inventory: 2681
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 15.24mm
Length 36.83mm
Height Seated (Max) 5.08mm
Technical
Controller Type Nonvolatile RAM
Supply Current-Max (Isup) 80mA
Adjustable Threshold NO
Analog IC - Other Type POWER SUPPLY MANAGEMENT CIRCUIT
Number of Channels 3
Supply Voltage-Min (Vsup) 4.5V
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status Not Qualified
Pin Count 28
Base Part Number DS1212
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 4.75V~5.5V
Technology CMOS
Subcategory Power Management Circuits
HTS Code 8542.31.00.01
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 1999
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Number of Pins 28
Surface Mount NO
Package / Case 28-DIP (0.600, 15.24mm)
Mounting Type Through Hole
