DS1210S+
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Memory - Controllers
Description
Surface Mount Lead Free GULL WING DUAL Nonvolatile RAM IC Controller 0C~70C 4.75V~5.5V 7.4mm 5mA
PDF
/
Buying Options
Total Price: USD $4.56
Unit Price: USD $4.56475
≥1 USD $4.56475
≥10 USD $3.7449
≥100 USD $3.62805
≥500 USD $3.5112
≥1000 USD $3.39435
Inventory: 57
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 7.4mm
Length 10.1mm
Height 2.35mm
Technical
Controller Type Nonvolatile RAM
Supply Current-Max (Isup) 80mA
Adjustable Threshold NO
Memory Type RAM
Operating Supply Current 5mA
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Number of Channels 3
Power Supplies 5V
Operating Supply Voltage 5V
Output Voltage 5.5V
Pin Count 16
Base Part Number DS1210
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.5V
Technology CMOS
Subcategory Power Management Circuits
HTS Code 8542.31.00.01
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2003
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Weight 200.686274mg
Number of Pins 16
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 6 Weeks
