5146733-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Memory Connectors - PC Card Sockets
Description
Conn PCMCIA HDR 68 POS 1.27mm Solder ST SMD Tube 5A/Contact
PDF
/
Buying Options
Total Price: USD $12.52
Unit Price: USD $12.5224
≥1 USD $12.5224
≥10 USD $11.322177
≥100 USD $9.824549
≥500 USD $9.405211
Inventory: 653
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Material Brass
Contact Plating Gold, Tin
Mount Surface Mount
Mounting Type Surface Mount
Mounting Feature Normal, Standard - Top
Housing Material Polymer
Underplate Material Nickel
Technical
Packaging Tube
Published 2005
Feature Board Guide
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Connector
Number of Positions 68
Max Operating Temperature 70°C
Min Operating Temperature -10°C
Color Black
Number of Rows 2
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.27mm
Total Number of Contacts 68
Orientation Straight
Shielding Unshielded
Depth 5.5mm
Contact Finish Gold
Card Type PCMCIA
ELV Compliant
Max Voltage Rating (AC) 100V
Sealable No
Circuit Application Power
Preloaded Yes
Insertion, Removal Method Push In, Pull Out
Dimensions
Length 56.2mm
Contact Finish Thickness 30.0μin 0.76μm
Height Above Board 0.551 14.00mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
