5-5569331-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Memory Connectors - PC Card Sockets
Description
Memory Card Connectors HEADER ASSY SHLD DUAL 15 SER 3
PDF
/
Inventory: 919
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness 10.0μin 0.25μm
Technical
Insertion, Removal Method Push In, Pull Out
ELV Compliant
Card Type PCMCIA
UL Flammability Code 94V-0
Contact Gender MALE
Contact Finish Gold
Shielding Shielded
Orientation Right Angle
Total Number of Contacts 15
Pitch 800μm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 2
Color Black
Number of Positions 15
Connector Type Connector
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Keyed, Shielded
Series INFOPORT
Packaging Tape & Reel (TR)
Physical
Housing Material Nylon
Mounting Type Board Edge, Straddle Mount
Mount Edge, Straddle Mount, Surface Mount
Contact Material Bronze
