EMF-134-01-S-D
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Memory Connectors - PC Card Sockets
Description
PC Card Socket
PDF
/
Inventory: 3096
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mount Edge, Straddle Mount
Mounting Type Board Edge, Straddle Mount
Insulation Material LIQUID CRYSTAL POLYMER (LCP)
Technical
Packaging Tube
Published 2003
Series Flexcard? EMF
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Connector
Number of Positions 68
Number of Rows 2
Gender Female
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.27mm
Total Number of Contacts 68
Orientation Straight
Number of Conductors ONE
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 1.855 inch
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Body Depth 0.18 inch
Contact Style SQ PIN-SKT
Contact Resistance 10mOhm
Body/Shell Style SOCKET
Termination Type SURFACE MOUNT
Max Current Rating 1A
Polarization Key POLARIZED HOUSING
Contact Pattern RECTANGULAR
Mating Contact Row Spacing 0.05 inch
Insulator Color BLACK
Insertion, Removal Method Push In, Pull Out
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
