EMF-130-01-S-D
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Memory Connectors - PC Card Sockets
Description
FLEXCARD TIGER EYE CONTACT PC Card Socket
PDF
/
Inventory: 5525
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 1 Weeks
Physical
Contact Material Copper
Mount Edge
Mounting Type Board Edge, Straddle Mount
Housing Material Polymer
Technical
Packaging Tube
Published 2012
Series Flexcard? EMF
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
ECCN Code EAR99
Connector Type Connector
Number of Positions 60
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Number of Rows 2
Gender Female
Additional Feature FLEXCARD, TIGER EYE CONTACT
HTS Code 8536.69.40.40
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.27mm
Total Number of Contacts 60
Orientation Straight
Depth 7.69mm
Number of Conductors ONE
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Mating Information MULTIPLE MATING PARTS AVAILABLE
UL Flammability Code 94V-0
Contact Style SQ PIN-SKT
Contact Resistance 10mOhm
Body/Shell Style SOCKET
Max Current Rating 1A
Polarization Key POLARIZED HOUSING
Contact Pattern RECTANGULAR
Insertion Force-Max .834 N
Mating Contact Row Spacing 0.05 inch
Insulator Color BLACK
Insertion, Removal Method Push In, Pull Out
Dimensions
Length 41.86mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
