EMF-105-01-LM-D
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Memory Connectors - PC Card Sockets
Description
PC Card Socket
PDF
/
Inventory: 3537
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness 10.0μin 0.25μm
Technical
Insertion, Removal Method Push In, Pull Out
Insulator Color BLACK
Mating Contact Row Spacing 0.05 inch
Contact Pattern RECTANGULAR
Polarization Key POLARIZED HOUSING
Max Current Rating 1A
Termination Type SURFACE MOUNT
Body/Shell Style SOCKET
Contact Style SQ PIN-SKT
Body Depth 0.18 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Body Length or Diameter 0.405 inch
Reliability COMMERCIAL
Contact Finish Gold
Number of Conductors ONE
Orientation Straight
Total Number of Contacts 10
Pitch 1.27mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Female
Number of Rows 2
Number of Positions 10
Connector Type Connector
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Flexcard? EMF
Published 2012
Packaging Tube
Physical
Insulation Material LIQUID CRYSTAL POLYMER (LCP)
Mounting Type Board Edge, Straddle Mount
Mount Edge
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 3 Weeks
