5031820853

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Memory Connectors - PC Card Sockets
Description MOLEX 503182-0853CONNECTOR, MICRO SD, SMT, R/A, PUSH PUSH
PDF
/
Buying Options
Total Price: USD $0.76
Unit Price: USD $0.7568
≥1 USD $0.7568
≥10 USD $0.6952
≥100 USD $0.6688
≥500 USD $0.6424
Inventory: 150097
Minimum: 1
-
+

Technical Details

Physical

Contact Material COPPER ALLOY
Mounting Type Surface Mount, Right Angle
Mounting Feature Normal, Standard - Top
Insulation Material LIQUID CRYSTAL POLYMER (LCP)
Board Mounting Option FITTING NAIL

Technical

Packaging Tape & Reel (TR)
Published 2013
Series 503182
Feature Switch
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Connector and Ejector
Number of Positions 10 (8 + 2)
Number of Rows 1
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Total Number of Contacts 8
Terminal Pitch 1.0922mm
Number of Conductors ONE
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 0.557 inch
Number Of PCB Rows 1
PCB Contact Pattern RECTANGULAR
Body Breadth 0.057 inch
Contact Gender MALE
Body Depth 0.589 inch
Card Type Secure Digital - microSD?
Mating Contact Pitch 0.043 inch
Number of Ports 1
Contact Pattern RECTANGULAR
Insertion, Removal Method Push In, Push Out

Dimensions

Height Above Board 0.057 1.45mm

Compliance

RoHS Status ROHS3 Compliant
