5009010801
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Memory Connectors - PC Card Sockets
Description
1.10mm Pitch TransFlash Memory Card Connector, Hinge Type, Round Corner Top
PDF
/
Buying Options
Total Price: USD $3.92
Unit Price: USD $3.9248
≥1 USD $3.9248
≥10 USD $3.45488
≥100 USD $2.748416
Inventory: 1139
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material NOT SPECIFIED
Mounting Type Surface Mount, Right Angle
Mounting Feature Normal, Standard - Top
Insulation Material LIQUID CRYSTAL POLYMER (LCP)
Board Mounting Option FITTING NAIL
Technical
Packaging Tape & Reel (TR)
Published 2009
Series 500901
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Connector and Ejector
Number of Positions 8
Number of Rows 1
Additional Feature ROHS COMPLIANT
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 8
Terminal Pitch 1.0922mm
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 0.542 inch
Number Of PCB Rows 1
PCB Contact Pattern RECTANGULAR
Body Breadth 0.076 inch
Contact Gender MALE
Operating Temperature (Min) -25°C
Body Depth 0.571 inch
Rated Current (Signal) 0.5A
Card Type Secure Digital - microSD?
Insulation Resistance 1000000000Ohm
Mating Contact Pitch 0.043 inch
Body/Shell Style SOCKET
Dielectric Withstanding Voltage 500VAC V
Number of Ports 1
Durability 1000 Cycles
Contact Pattern RECTANGULAR
Insulator Color WHITE
Insertion, Removal Method Hinged Lid
Dimensions
Contact Finish Thickness 20.0μin 0.51μm
Plating Thickness 20μin
Height Above Board 0.076 1.92mm
Compliance
RoHS Status ROHS3 Compliant
