9-2199154-9
RoHS
/
Package /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
Non-RoHS Compliant 2015 Vertical Board Lock Latches DIMM Socket UL94V-0 221C 750mA 30.0muin 0.76mum
PDF
/
Inventory: 3257
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Technical
Hole Diameter 1.1938 mm
Circuit Application Signal
Contact Current Rating 750mA
Sealable No
Memory Type DDR4 SDRAM
Connector Style DIMM
Max Current Rating 750mA
Row Spacing 2.2 mm
Lead Length 2.09804mm
Housing Color Blue
Number of Contacts 288
Contact Finish Gold
Orientation Vertical
Pitch 850μm
Number of Rows 2
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Number of Positions 288
Part Status Active
Feature Board Lock, Latches
Published 2015
Packaging Tray
Physical
Housing Material Nylon
Mounting Feature Normal, Standard - Top
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 11 Weeks
