822134-3 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description IC & Component Sockets 72 POS LOW PROFIL ML
PDF
/
Inventory: 4432
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant

Dimensions

Plating Thickness 200μin
Contact Finish Thickness 200.0μin 5.08μm

Technical

Standards MO-116
Hole Diameter 1.63 mm
Insertion Force-Max LIF N
Durability 25 Cycles
Memory Type RAM
Connector Style SIMM
Termination Type SOLDER
Body/Shell Style SOCKET
Contact Resistance 30mOhm
Contact Style BELLOWED TYPE
Rated Current (Signal) 1A
Body Depth 0.495 inch
Lead Length 3.56mm
UL Flammability Code 94V-0
Contact Gender FEMALE
PCB Contact Pattern STAGGERED
Lead Pitch 1.27mm
Number Of PCB Rows 2
Body Length or Diameter 4.54 inch
Reliability COMMERCIAL
Contact Finish Tin
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 1A
Total Number of Contacts 72
Pitch 1.27mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Additional Feature LOW PROFILE
Number of Rows 1
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 72
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Board Guide, Latches
Series Micro-Edge
Published 1997
Packaging Tube

Physical

Housing Material Polymer
Mounting Feature Normal, Standard - Top
Mounting Type Through Hole, 22° Angle
Mount Through Hole
Contact Material Bronze

Supply Chain

Factory Lead Time 7 Weeks
