6318228-1
RoHS
/
Package /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
CONN SKT SODIMM 124POS R/A SMD
PDF
/
Buying Options
Total Price: USD $10.74
Unit Price: USD $10.73975
≥1 USD $10.73975
≥10 USD $8.8122
≥100 USD $8.5367
≥500 USD $8.2612
≥1000 USD $7.9857
Inventory: 193
Minimum: 1
-
+
Technical Details
Physical
Contact Material PHOSPHOR BRONZE
Mounting Type Surface Mount, Right Angle
Mounting Feature Normal, Standard - Top
Insulation Material THERMOPLASTIC
Board Mounting Option PEG
Technical
Packaging Tray
Published 2005
JESD-609 Code e4
Feature Board Guide, Latches
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Positions 124
Number of Rows 2
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 124
Terminal Pitch 0.8mm
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 2.528 inch
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 85°C
Body Breadth 0.157 inch
Contact Gender FEMALE
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Housing Color Black
Body Depth 0.27 inch
Rated Current (Signal) 0.5A
Contact Style CENTRONIC
Contact Resistance 80mOhm
Insulation Resistance 100000000Ohm
Mating Contact Pitch 0.031 inch
Body/Shell Style SOCKET
Dielectric Withstanding Voltage 250VAC V
Connector Style SODIMM
Number of Ports 1
Durability 50 Cycles
Contact Pattern RECTANGULAR
Dimensions
Contact Finish Thickness Flash
Compliance
RoHS Status RoHS Compliant
