5822134-3
RoHS
RoHS compliant
RoHS compliantPackage Metal
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
CONN SKT SIMM 72POS PCB
PDF
/
Buying Options
Total Price: USD $12.23
Unit Price: USD $12.227038
≥1 USD $12.227038
≥10 USD $11.736013
≥30 USD $10.885254
≥100 USD $10.143465
Inventory: 1774
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Length - Tail 2.92mm
Contact Finish Thickness 200.0μin 5.08μm
Length 115.32mm
Technical
Standards MO-116
Hole Diameter 1.63 mm
Circuit Application Signal
Sealable No
Memory Type RAM
Connector Style SIMM
Max Current Rating 1A
ELV Compliant
Lead Length 2.921mm
Number of Contacts 72
Contact Finish Tin
Current Rating 1A
Depth 13.72mm
Orientation Right Angle
Pitch 1.27mm
Gender Receptacle
Number of Rows 1
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 72
Connector Type Socket
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide, Latches
Series Micro-Edge
Published 1997
Packaging Box
Physical
Body Material Liquid Crystal Polymer, Polymer
Housing Material Polymer
Insulation Material Polymer
Mounting Feature Normal, Standard - Top
Package / Case Metal
Mounting Type Through Hole, 22° Angle
Mount Through Hole
Contact Plating Tin
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 9 Weeks
