2309413-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
DDR4 SODIMM 260P 9.2H STD
PDF
/
Buying Options
Total Price: USD $1.59
Unit Price: USD $1.5928
≥1 USD $1.5928
≥10 USD $1.45376
≥100 USD $1.410816
≥500 USD $1.39656
≥1000 USD $1.29624
Inventory: 1141
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Material Gold, Nickel
Contact Plating Gold, Nickel
Mount Surface Mount
Mounting Type Surface Mount, Right Angle
Mounting Feature Normal, Standard - Top
Housing Material Thermoplastic
Technical
Packaging Tape & Reel (TR)
Published 2017
Series AdvancedMC
Feature Board Guide, Latches
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Positions 260
Max Operating Temperature 85°C
Min Operating Temperature -55°C
Number of Rows 2
Voltage - Rated 25V
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 500μm
Total Number of Contacts 260
Orientation Right Angle
Current Rating 500mA
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Contact Gender FEMALE
UL Flammability Code 94V-0
Housing Color Black
Body Depth 1.017 inch
Rated Current (Signal) 0.5A
Contact Style BELLOWED TYPE
Row Spacing 8.1788 mm
Body/Shell Style SOCKET
Max Current Rating 500mA
Polarization Key POLARIZED HOUSING
Connector Style SODIMM
Memory Type DDR4 SDRAM
Contact Pattern RECTANGULAR
Sealable No
Contact Current Rating 500mA
Circuit Application Power
Dimensions
Height 18.8mm
Contact Finish Thickness Flash
Stack Height 9.1948mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
