2-2013311-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
Conn DDR3 SO DIMM SKT 204 POS 0.6mm Solder ST SMD Embossed T/R
PDF
/
Buying Options
Total Price: USD $3.21
Unit Price: USD $3.212
≥1 USD $3.212
≥10 USD $2.8644
≥100 USD $2.850144
≥500 USD $2.820928
≥1000 USD $2.5432
≥3000 USD $2.528592
Inventory: 7083
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Stack Height 9.1948mm
Contact Finish Thickness Flash
Length 75.9mm
Technical
Circuit Application Power
Contact Current Rating 500mA
Sealable No
Durability 50 Cycles
Memory Type DDR3 SDRAM
Connector Style SODIMM
Polarization Key POLARIZED HOUSING
Max Current Rating 500mA
ELV Compliant
Body/Shell Style SOCKET
Row Spacing 8.1788 mm
Insulation Resistance 50000000Ohm
Contact Style BELLOWED TYPE
Rated Current (Signal) 0.5A
Housing Color Black
Contact Gender FEMALE
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Depth 26.5mm
Orientation Straight
Total Number of Contacts 204
Pitch 609.6μm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 2
Min Operating Temperature -67°C
Max Operating Temperature 185°C
Number of Positions 204
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide, Latches
Published 2011
Packaging Tape & Reel (TR)
Physical
Housing Material Thermoplastic
Mounting Feature Reverse
Mounting Type Surface Mount, 25° Angle
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 15 Weeks
